Availability:
Out of stock
Edelbrock 2838 { Sellable : Yes }
by Edelbrock
SKU ds_BDVJ_2838
Proudly Canadian
Albertan Owned
Secure Payments
Financing Available
Trusted Brands
Top-Quality Suppliers
Sold out
Original price
$639.38
-
Original price
$639.38
Original price
$639.38
$639.38
$639.38
-
$639.38
Current price
$639.38
Description
Edelbrock part #2838 Victor Jr. Ford 4.6L SOHC intake manifold for Ford 4.6L SOHC Modular engines allows the customer to take any 1999-2004 SOHC Modular 4.6L engine and convert it for use with a carburetor. Timing control module available separately. Not intended for or as a stock replacement intake manifold.
Specifications
| Basic Operating RPM Range | 3500-7500 |
| Center Maximum Height | 4.750 |
| CNC Ported | No |
| Description_ABR | Intake Mnfld |
| Description_ASM | Ford:Modular 2V:281 (4.6L) |
| Description_DEF | Engine Intake Manifold |
| Description_DES | INTAKE MANIFOLD |
| Description_EXT | Victor Jr. Intake Manifold for Small-Block Ford 4.6L SOHC Modular Engines is Designed for 4.6L Ford Racing Applications. Not Recommended for Stock Replacement. Electronics Not Included. Accepts 4150-Series Carburetor. Non-EGR. |
| Description_FAB | Convert To Use With Carburetor |
| Description_FAB | Includes Electronic Timing Control Module |
| Description_INV | Victor Jr Ford 4.6L Modular Carburetor |
| Description_KEY | 2838; Ford; Edelbrock; Intake Manifold; Intake; Manifold; Single-Plane; Victor JR.; Satin |
| Description_LAB | Victor Jr. Ford 4.6L SOHC Modular Carburetor Intake Manifold Without Electronics |
| Description_MKT | Edelbrock part #2838 Victor Jr. Ford 4.6L SOHC intake manifold for Ford 4.6L SOHC Modular engines allows the customer to take any 1999-2004 SOHC Modular 4.6L engine and convert it for use with a carburetor. Timing control module available separately. Not intended for or as a stock replacement intake manifold. |
| Description_SHO | { Sellable : Yes } |
| Description_SHP | { eo : 5in.} |
| Description_TRA | Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum. |
| Description_TRA | Manifold height: A-4.75", B-4.75", 0 Deg carb angle |
| Description_TRA | Port exit dimensions: 1.42" x 1.72" |
| Description_TRA | Recommended intake gasket: OEM factory gaskets |
| Description_TRA | Throttle body recommendations: Edelbrock #38780 4150 style 4 V or #3848 competition EFI elbow and #3818 90mm throttle body |
| Description_TRA | Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant #1076, DO NOT USE END SEALS GASKETS. |
| Description_TRA | • Recommended intake gasket: OEM factory gaskets • Manifold height: A-4.75in.; B-4.75in.; 0deg. carb angle • Throttle body recommendations: Edelbrock # 38780 4150 style 4 V or # 3848 competition EFI elbow and # 3818 90mm throttle body • Port exit dimensions: 1.42in. x 1.72in. • Use RTV sealant to properly seal end seals; such as Edelbrock High Temp Silicone sealant # 1076; DO NOT USE END SEALS GASKETS. • Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum. |
| EGR Port | No |
| finish | Satin |
| Flange Type | 4150 |
| Front Maximum Height | 4.750 |
| Gasket Or Seal Included | No |
| Grade Type | Performance |
| height | 9.5 |
| length | 24.0 |
| LTL | N |
| Material | Aluminum |
| Rear Maximum Height | 4.750 |
| RGL | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Series | Victor |
| Single Or Dual Plane Type | Single |
| Vehicle Model | Ford |
| weight | 21.4 |
| width | 16.2 |
