Description
Specifications
Basic Operating RPM Range | 3500-8000 |
Center Maximum Height | 5.500 |
CNC Ported | No |
Description_ABR | Intake Mnfld |
Description_ASM | Chevrolet:Small-Block Gen I:262 (4.3L)/265 (4.3L)/267 (4.4L)/283 (4.6L)/302 (4.9L)/305 (5.0L)/307 (5.0L)/327 (5.4L)/350 (5.7L)/400 (6.6L) |
Description_DEF | Engine Intake Manifold |
Description_DES | INTAKE MANIFOLD |
Description_EXT | Edelbrock Super Victor 23 Degree Intake Manifold For Chevrolet 262-400 Small-Block V8 |
Description_FAB | About .50 in. Taller Than Victor Jr PN[2975] |
Description_FAB | Designed for 23 Degree Standard Port Heads |
Description_FAB | Designed For Eng. w/Conventional Rect. Port Heads |
Description_FAB | Direct Line of Sight Flow Path Maximizes Flow |
Description_FAB | For 3500 to 8000 RPM High-Performance Engines |
Description_FAB | Great Mid-Range Torque For Short Track Power |
Description_FAB | Improved Throttle Response For 60 ft. Times |
Description_FAB | Runners Have A 2.80 Square In. Cross-Section |
Description_INV | Super Victor SBC Intake Manifold |
Description_KEY | 2925; Chevy; Chevrolet; Edelbrock; Intake Manifold; Intake; Manifold; Single-Plane; Super Victor; Satin |
Description_LAB | Super Victor 23 Degree Intake Manifold Small-Block Chevy |
Description_MKT | Edelbrock part #2925 Super Victor 23-degree intake manifold is designed for heads with a standard port location, the runners match the "flat floor" entry of the latest 23-degree heads. Carb pad height is 5-1/2" (from end seals) and overall, this intake is about one-inch taller than our Victor Jr. intake #2975. Runners have a 2.80 square-inch cross-section. |
Description_SHO | { Sellable : Yes } |
Description_SHP | { eo : 2in.} |
Description_TRA | Carb recommendations: Use appropriate standard flange square-bore racing carb. |
Description_TRA | Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum. |
Description_TRA | No provisions for exhaust heated chokes or EGR. |
Description_TRA | NPT/Pipe thread fittings require the use of Teflon tape or paste on threads to ensure proper seal. |
Description_TRA | Optimum cylinder head port opening size should be as close as possible to the size of the gasket being used. |
Description_TRA | Recommended intake gasket: Edelbrock #7201 |
Description_TRA | Sealant must be used on intake bolt threads if the threads extend into lifter valley or coolant passage. |
Description_TRA | To ensure maximum performance and a proper seal, Edelbrock gaskets which are specifically designed and manufactured for use with Edelbrock parts must be used. |
Description_TRA | Use RTV sealant to properly seal end seals, such as Edelbrock High Temp Silicone sealant #1076, DO NOT USE END SEALS GASKETS. |
Description_TRA | • Recommended intake gasket: Edelbrock # 7201 • Carb recommendations: Use appropriate standard flange square-bore racing carb. • No provisions for exhaust heated chokes or EGR. • Use RTV sealant to properly seal end seals; such as Edelbrock High Temp Silicone sealant # 1076; DO NOT USE END SEALS GASKETS. • Optimum cylinder head port opening size should be as close as possible to the size of the gasket being used. • Hardened washers Must be used with intake bolts to ensure proper torque and prevent galling of the aluminum. • Sealant must be used on intake bolt threads if the threads extend into lifter valley or coolant passage. • NPT/Pipe thread fittings require the use of Teflon tape or paste on threads to ensure proper seal. • To ensure maximum performance and a proper seal; Edelbrock gaskets which are specifically designed and manufactured for use with Edelbrock parts must be used. |
EGR Port | No |
finish | Satin |
Flange Type | 4150 |
Front Maximum Height | 5.500 |
Gasket Or Seal Included | No |
Grade Type | Performance |
height | 7.5 |
length | 23.62 |
LTL | N |
Material | Aluminum |
Rear Maximum Height | 5.500 |
RGL | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
Series | Victor |
Single Or Dual Plane Type | Single |
Vehicle Model | Chevrolet |
weight | 20.0 |
width | 14.75 |
