Description
The Edelbrock #60609 Performer RPM CNC Bare Cylinder Head has the same specifications as our popular Performer RPM cylinder head for 1962-79 389-455 c.i.d. Pontiac engines, but feature a CNC machined combustion chamber. The CNC machined chamber results in a consistent and precise chamber for improved flow performance. Performer RPM CNC cylinder head is available in two chamber sizes. The 87cc chamber version is ideal for 9.5:1 engines and will deliver excellent street performance on low octane fuel. The Edelbrock #60609 Performer RPM CNC cylinder head is patterned after the same port flange configuration as the 1969-1970 Ram-Air IV Pontiac Cylinder Head.
Specifications
| Cylinder Head Type | Rectangular Port |
| Description_ABR | Cyl. Head |
| Description_ASM | Pontiac:-:326 (5.3L)/350 (5.7L)/389 (6.4L)/400 (6.6L)/421 (6.9L)/428 (7.0L)/455 (7.4) |
| Description_DEF | Engine Cylinder Head |
| Description_DES | CYLINDER HEAD |
| Description_EXT | The Edelbrock #60609 Performer RPM CNC Bare Cylinder Heads have the same specifications as our popular Performer RPM cylinder heads for 1962-79 389-455 c.i.d. Pontiac engines, but feature a CNC machined combustion chamber. |
| Description_EXT | The Edelbrock #60609 Performer RPM CNC Bare Cylinder Heads have the same specifications as our popular Performer RPM cylinder heads for 1962-79 389-455 c.i.d. Pontiac engines; but feature a CNC machined combustion chamber. |
| Description_FAB | Intended As Direct Replacement For Factory Heads |
| Description_FAB | Maximize Streetable Compression |
| Description_FAB | Out-of-the-Box Bolt-On Performance |
| Description_FAB | Patterned After The Ram Air IV Pontiac Cyl. Head |
| Description_INV | Edelbrock Pontiac Cylinder Head |
| Description_KEY | Edelbrock; Pontiac Head; 87cc Bare;V8; Cylinder Head; 60609 |
| Description_LAB | RPM Pontiac CNC Chamber 87cc Bare |
| Description_MKT | The Edelbrock #60609 Performer RPM CNC Bare Cylinder Head has the same specifications as our popular Performer RPM cylinder head for 1962-79 389-455 c.i.d. Pontiac engines, but feature a CNC machined combustion chamber. The CNC machined chamber results in a consistent and precise chamber for improved flow performance. Performer RPM CNC cylinder head is available in two chamber sizes. The 87cc chamber version is ideal for 9.5:1 engines and will deliver excellent street performance on low octane fuel. The Edelbrock #60609 Performer RPM CNC cylinder head is patterned after the same port flange configuration as the 1969-1970 Ram-Air IV Pontiac Cylinder Head. |
| Description_SHO | { Sellable : Yes } |
| Description_SHP | { eo : 3in.} |
| Description_TRA | Bare heads will have valve guides and seats installed, but will require final sizing and a valve job to match the valves you will be using. |
| Description_TRA | Deck thickness: 5/8" |
| Description_TRA | Edelbrock head bolt kit #8549 |
| Description_TRA | Features CNC machined combustion chamber for a consistent and precise chamber for improved flow performance and spark plug location - These heads require Ram Air IV (round port) style exhaust manifolds or headers |
| Description_TRA | Match with Edelbrock complete head gasket set #7382. |
| Description_TRA | Pushrod diameter: 5/16" (width of slot in guide plate). |
| Description_TRA | • Bare heads will have valve guides and seats installed; but will require final sizing and a valve job to match the valves you will be using. • Features CNC machined combustion chamber for a consistent and precise chamber for improved flow performance and spark plug location • These heads require Ram Air IV (round port) style exhaust manifolds or headers • Edelbrock head bolt kit #8549 • Match with Edelbrock complete head gasket set #7382. • Deck thickness: 5/8in. • Pushrod diameter: 5/16in. (width of slot in guide plate). |
| Emission | N/A |
| Engine Make/Size | Pontiac 326-455 |
| finish | Cast Aluminum |
| height | 8.18 |
| length | 24.75 |
| LTL | N |
| Preparation | Bolt On (Not Required) |
| Type | Complete |
| Usage | Street/Hi-Performance |
| WARNING CA Proposition 65 | Yes |
| WARNING CA Proposition 65 Message | WARNING: This product can expose you to Lead; which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information; visit www.P65warnings.ca.gov. |
| weight | 36.25 |
| width | 10.44 |
