Description
Edelbrock part #61905 Performer small-block Chevy LT1 (1992-97) Performer complete cylinder head delivers 24 horsepower over stock and raise the peak power level by 500 rpm. This head is designed to accept factory style self-aligning rockers. This Performer LT1 cylinder head is 50-state street legal and accept factory center bolt valve covers. It features exhaust ports in the stock location for use with stock or aftermarket exhaust manifolds and headers. Match with RPM Air-Gap intake #7107, throttle body #3809 and camshaft #2108 for the Total Power Package combo.Cylinder Head Specifications: - Exhaust port location: Stock- Spark plug fitment: 14mm x 3/4 reach, gasket seat
Specifications
| Camshaft Type | Hydraulic Roller |
| CNC Ported | No |
| Combustion Chamber Volume | 54 |
| Construction Type | Complete |
| Cylinder Head Type | Standard |
| Deck Thickness | 0.625 |
| Description_ABR | Cyl. Head |
| Description_ASM | Chevrolet:Small-Block Gen II LT1:350 (5.7L) |
| Description_DEF | Engine Cylinder Head |
| Description_DES | CYLINDER HEAD |
| Description_EXT | Edelbrock part #61905 Performer small-block Chevy LT1 (1992-97) Performer cylinder heads deliver 24 horsepower over stock and raise the peak power level by 500 rpm. |
| Description_FAB | 8.8:1 Compression With 1987 And Up TBI Dished Pistons |
| Description_FAB | 9.2:1 Compression with Flat Top Pistons |
| Description_FAB | Complete 50-State Street Legal Alum Cylinder Head |
| Description_FAB | Design That Improves Intake Port Alignment |
| Description_FAB | Match with Edelbrock Multi-Point EFI to Maximize |
| Description_FAB | Out-of-the-Box Bolt-On Performance |
| Description_FAB | Outstanding High Performance Street Head |
| Description_FAB | Provides A Semi-Open Combustion Chamber |
| Description_INV | Edelbrock Chevy LT1 Prf Cylinder Head |
| Description_KEY | Edelbrock; Chevy LT1; LT1; V8; Performer LT1; 1992-97 LT1 Engines; Hydraulic Roller Cam; 54cc; Complete; 61905 |
| Description_LAB | Performer LT1 Cylinder Head (54cc) |
| Description_MKT | Edelbrock part #61905 Performer small-block Chevy LT1 (1992-97) Performer complete cylinder head delivers 24 horsepower over stock and raise the peak power level by 500 rpm. This head is designed to accept factory style self-aligning rockers. This Performer LT1 cylinder head is 50-state street legal and accept factory center bolt valve covers. It features exhaust ports in the stock location for use with stock or aftermarket exhaust manifolds and headers. Match with RPM Air-Gap intake #7107, throttle body #3809 and camshaft #2108 for the Total Power Package combo. Cylinder Head Specifications: - Exhaust port location: Stock - Spark plug fitment: 14mm x 3/4 reach, gasket seat |
| Description_MKT | Edelbrock part #61905 Performer small-block Chevy LT1 (1992-97) Performer complete cylinder head delivers 24 horsepower over stock and raise the peak power level by 500 rpm. This head is designed to accept factory style self-aligning rockers. This Performer LT1 cylinder head is 50-state street legal and accept factory center bolt valve covers. It features exhaust ports in the stock location for use with stock or aftermarket exhaust manifolds and headers. Match with RPM Air-Gap intake #7107, throttle body #3809 and camshaft #2108 for the Total Power Package combo.Cylinder Head Specifications: - Exhaust port location: Stock- Spark plug fitment: 14mm x 3/4 reach, gasket seat |
| Description_SHO | { Sellable : Yes } |
| Description_SHP | { eo : 1in.; eo_carb_number : D-215-70in.; eo_carb_link : https:/ww3.arb.ca.gov/msprog/aftermkt/devices/eo/d-215-70.pdf } |
| Description_TRA | Exhaust Gasket: Edelbrock #7248 |
| Description_TRA | Head Bolt Kit: Edelbrock #8550 |
| Description_TRA | Head Gasket: Edelbrock #7342 |
| Description_TRA | Intake Gasket: Fel-Pro #7243 |
| Description_TRA | Recommended spark plugs: Champion RC12YC |
| Description_TRA | • Head Bolt Kit: Edelbrock # 8550 • Head Gasket: Edelbrock # 7342 • Intake Gasket: Fel-Pro # 7243 • Exhaust Gasket: Edelbrock # 7248 • Recommended spark plugs: Champion RC12YC |
| EGR Port | No |
| Emission | Non-Emissions |
| Engine Make/Size | Chevy LT1 |
| Exhaust Port Location | Standard |
| Exhaust Runner Volume | 60 |
| Exhaust Valve Diameter | 1.55 |
| Family | Performer |
| finish | Polished |
| Grade Type | Performance |
| Guide Material | Manganese Bronze |
| Guide Plates Included | No |
| Head Casting Number | N/A |
| height | 7.19 |
| Horsepower | 300-450 |
| Intake Runner Volume | 170 |
| Intake Valve Diameter | 1.94 |
| length | 22.19 |
| LTL | N |
| Material | Aluminum |
| Preparation | Bolt On (Not Required) |
| Push Rod Diameter | (Suggested) 0.375 |
| Quantity | Sold Individually |
| Retainer Included | Yes |
| RGL | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Seat Angle | Exhaust 45 deg/Intake 45 |
| Seat Material | Ductile Iron |
| Series | Performer |
| Type | Complete |
| Usage | Racing |
| Valve Angle | 23 |
| Valve Included | Yes |
| Valve Spring Diameter | 1.46 |
| Valve Spring Maximum Lift | 0.600 |
| Valve Springs Included | Yes |
| Valve Stem Diameter | 0.3125 |
| WARNING CA Proposition 65 | Yes |
| WARNING CA Proposition 65 Message | WARNING: This product can expose you to Lead; which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information; visit www.P65warnings.ca.gov. |
| weight | 31.65 |
| width | 10.12 |
