Rough Country 27220A 6 Inch GM NTD Suspension Lift Kit 99-06 Silverado/Sierra 1500 4WD Rough Country
Description
We've raised the bar on our 6 inch NTD suspension for '99 - '06 Chevy/GMC 1500 pickups! Gain greater clearance, better handling, and the cleanest looking 6-inch lift available!
A set of lifted front knuckles and 6.25in rear fabricated, anti-wrap blocks allow your 1500 to run up to 35in tires, while a full set of high clearance drop crossmembers, differential drop brackets and non torsion bar drop brackets keep everything tucked, hidden, and at optimum angles.
This fully loaded suspension lift also includes a set of (4) Premium N3 Shocks, front CV spacers, sway-bar links, and a protective skid plate to give you everything you need to get rolling in one of our best kits, now at our best price ever!
Features:
- Torsion bars stay in factory location
- Redesigned for easier installation
- Maintains factory ride quality
- Applicable with Auto Trac equipped models
- Unmatched ground clearance
- Axles maintain factory position and angle
- No drivetrain or exhaust modifications Required
- Designed to reuse factory compression travel stops
- Includes application valved N3 series shock absorbers which offer the best in balanced performance for on and off-road use.
- Fabricated blocks are stronger and offer a longer lifespan than cast blocks.
- Specially designed anti-axle wrap rear blocks maintain stock ride quality while eliminating common lift block problem.
Notes: Will fit 2007 Classic models. Does Not fit HD models. Does Not fit 1999 Classic models. Frame bracket modification Required Differential modification Required Models equipped with a factory painted bumpers will Require trimming to valance and bumper. New fabricated lift block replaces your factory equipped block. If equipped with factory 17 inch wheels and purchasing new wheels - the new wheels must be 17 inch or larger. Torsion bar unloading tool Required for installation. Available below (#1067)
Details:
- Sold As Kit
- Drive 4WD
- Tire Info 1315/75 R16:16x8:4.5.0 inch- 2315/70 R17:17x9:5.0 inch:0mm 2315/65 R18:18x9:5.0 inch:0mm 2315/55 R20:20x9:5.0 inch:0mm 1 Models equipped with Factory 17-inch wheels cannot run smaller 16-inch wheels without checking for rotor/caliper clearance 2 If using wheels with -12mm offset or 4.5-inch backspacing, some minor inner fender trimming will be required
- Max Tire 35.0 inch
- Lift Height 6.0 inch
- Mount Style Bolt On
- Front Components Lifted knuckles Front crossmember Rear crossmember Non-torsion bar drop brackets Differential drop brackets Sway-bar links CV spacers Skid plate Hardware
- Rear Components 6.25.0 inch fabricated lift blocks U-bolts Hardware
Resources
Installation InstructionsSpecifications
brand_logo | https://www.asapnetwork.org/sites/default/files/brands/icons/rough%20country%20asap.jpg |
Description_ASC | 1999-2006:4WD:Chevy:Silverado 1500;2007-2007:4WD:Chevy:Silverado 1500 Classic;1999-2006:4WD:GMC:Sierra 1500;2007-2007:4WD:GMC:Sierra 1500 Classic |
Description_ASC | Manufacturer: Rough Country Suspension Systems; Part Number: 27220A; Weight (Lbs): 217.38; Install Time (Hours): 8-10; Wheel Backspacing (Inches): 4.5; Recommended Tire Size: 35-by-12.50 |
Description_ASC | Will fit 2007 "Classic" models. Does NOT fit HD models. Does NOT fit 1999 "Classic" models. Frame bracket modification required. Differential modification required. Models equipped with a factory painted bumpers will require trimming to valance and bumper. New fabricated lift block replaces your factory equipped block. If equipped with factory 17" wheels and purchasing new wheels - the new wheels must be 17" or larger. Torsion bar unloading tool required for installation. Available here! SKU: 1067 |
Description_ASM | 1999-2006:4WD:Chevy:Silverado 15002007-2007:4WD:Chevy:Silverado 1500 Classic1999-2006:4WD:GMC:Sierra 15002007-2007:4WD:GMC:Sierra 1500 Classic |
Description_ASM | 1999-2006:4WD:Chevy:Silverado 1500;2007-2007:4WD:Chevy:Silverado 1500 Classic;1999-2006:4WD:GMC:Sierra 1500;2007-2007:4WD:GMC:Sierra 1500 Classic |
Description_ASM | Chevrolet: 99-06 Silverado 1500 4WD; GMC: 99-06 Sierra 1500 4WD |
Description_DEF | Suspension Lift Kit |
Description_DES | 6-inch Non-Torsion Drop Suspension Lift Kit |
Description_DES | Suspension Lift Kit w/Shock |
Description_EXT | 6 Inch Lift Kit - Chevy Silverado & GMC Sierra 1500 4WD (1999-2006 & Classic) |
Description_EXT | Kit Contents: Front: Lifted knuckles, diff drop brackets, front/rear drop crossmbrs, skid plate, sway bar links, CV spacers, non torsion bar drop brackets; Rear: 6.25" fabricated anti-wrap lift blocks and u-bolts; Shocks: (4) N2.0 Shocks |
Description_EXT | Suspension Lift Kit w/Shock; 6 in. Lift; |
Description_FAB | Applicable with Auto Trac equipped models |
Description_FAB | Axles Maintain Factory Position And Angle |
Description_FAB | Designed To Reuse Factory Compression Travel Stop |
Description_FAB | Easier Installation |
Description_FAB | Maintain Stock Ride Quality |
Description_FAB | Maintains Factory Ride Quality |
Description_FAB | Newly Redesigned |
Description_FAB | No Drivetrain Or Exhaust Modifications Req. |
Description_FAB | Specially Designed Anti-Axle Wrap Rear Blocks |
Description_FAB | Torsion Bars Stay In Factory Location |
Description_FAB | Unmatched Ground Clearance |
Description_FAB | While Eliminating Common Lift Block Problem |
Description_FAB | Will Work w/Auto Trac |
Description_FAB | Will work with Auto Trac |
Description_INV | Rough Country Suspension Lift Kit |
Description_MKT | We've raised the bar on our 6" NTD suspension for '99 - '06 Chevy/GMC 1500 pickups! Gain greater clearance, better handling, and the cleanest looking 6-inch lift available! A set of lifted front knuckles and 6.25in rear fabricated, anti-wrap blocks allow your 1500 to run up to 35in tires, while a full set of high clearance drop crossmembers, differential drop brackets and non torsion bar drop brackets keep everything tucked, hidden, and at optimum angles. This fully loaded suspension lift also includes a set of (4) Premium N3 Shocks, front CV spacers, sway-bar links, and a protective skid plate to give you everything you need to get rolling in one of our best kits, now at our best price ever! |
Description_MKT | We've raised the bar on our 6" NTD suspension for '99 - '06 Chevy/GMC 1500 pickups! Gain greater clearance, better handling, and the cleanest looking 6-inch lift available! This kit features set of lifted front knuckles and 6.25in rear fabricated, anti-wrap blocks allow your 1500 to run up to 35in tires. while a full set of high clearance drop crossmembers, differential drop brackets and non torsion bar drop brackets keep everything tucked, hidden, and at optimum angles. Rough Country's 6" NTD Suspension Kit features (4) Premium N3 Nitrogen-charged shocks, giving your truck incredible ride-quality both on and off-road. Also included are a set of front CV spacers, sway-bar links, and a protective skid plate to give you everything you need to get rolling in one of our best kits, now at our best price ever! This all-inclusive kit comes with everything you need, and best of all this kit features Rough Country's Lifetime Replacement Warranty. |
Description_MKT | Weve raised the bar on our 6 in. NTD suspension for 99 - 06 Chevy/GMC 1500 pickups! Gain greater clearance, better handling, and the cleanest looking 6-inch lift available! This kit features set of lifted front knuckles and 6.25in rear fabricated, anti-wrap blocks allow your 1500 to run up to 35in tires. while a full set of high clearance drop crossmembers, differential drop brackets and non torsion bar drop brackets keep everything tucked, hidden, and at optimum angles.Ā Rough Countrys 6 in. NTD Suspension Kit features (4) Premium N3 Nitrogen-charged shocks, giving your truck incredible ride-quality both on and off-road. Also included are a set of front CV spacers, sway-bar links, and a protective skid plate to give you everything you need to get rolling in one of our best kits, now at our best price ever! This all-inclusive kit comes with everything you need, and best of all this kit features Rough Countrys Lifetime Replacement Warranty. |
Description_SHO | LftKt-Suspw/Shock |
Description_SHO | Suspension Lift Kit |
drive | 4WD |
height | 6.75 |
installation_time | 8-10 hours |
last_update | 2023-04-18 13:56:03 |
length | 30.25 |
lift_height | 6.0 inch |
max_tire | 35.0 inch |
mount_style | Bolt On |
prop_65_warning | CALIFORNIA WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov |
sold_as | Kit |
Universal | No |
vehicle_type | Truck/SUV |
weight | 56.5 |
width | 14.25 |
