Availability:
Out of stock
Edelbrock 450001 { Sellable : Yes }
by Edelbrock
SKU ds_BDVJ_450001
Proudly Canadian
Albertan Owned
Secure Payments
Financing Available
Trusted Brands
Top-Quality Suppliers
Sold out
Original price
$5,223.60
-
Original price
$5,223.60
Original price
$5,223.60
$5,223.60
$5,223.60
-
$5,223.60
Current price
$5,223.60
Description
Edelbrock part #450001 Big-Block Chevy Cast Iron Engine Block is cast and machined in the U.S.A. and made to last. Being that Edelbrock engine blocks are cast and machined in the U.S.A. allows us to precision machine them to our very own specifications. Engine block part #450001 is the perfect starting point for any Big-Block Chevy high performance engine build especially when used with an Edelbrock Total Power Package. When it comes to starting with the right base for your engine build.. make sure to choose the one made right here in the U.S.A.Edelbrock part #450001 Big-Block Chevy Cast Iron Engine Block is manufactured to the following specifications:- Block Type: Big-Block Chevy- Block Material: Cast Iron- Cylinder Wall: Siamese- Supplied Bore Size: 4.500"- Supplied Stroke Clearance: 4.500"- Max Recommended Bore: 4.600"- Max Recommended Stroke: 4.500"- Max Recommended C.I.: 598- Deck Height: 9.800"- Cam Bearing Bore ID: 2.120"- Camshaft Position: Standard BBC- Head Bolt Pattern: Standard BBC- Inside Head Stud Bosses: Yes- Lifter Bores: Standard BBC- Main Bearing Size: Standard BBC- Main Bearing Bore: 2.9375"- Main Caps: 4 Bolt Splayed Nodular Iron- Oil System: Main Priority- Oil Cooler Holes: Integral to Block- Rear Main Seal: 1-Piece- Hydraulic Roller Provisions: Accepts- Gen V, VI Link Bar- Stud and Bolt Holes: Blind Tapped- Tapped Holes: Standard Thread & Pitch- Timing Chain/Gears: Standard BBC Gen IV, V, VI- Timing Cover: Accepts- GEN V, VI 6 Bolt- Fuel Pump Boss: Yes- Starter: Standard Location- Clutch Linkage Boss: Yes
Specifications
| Description_ABR | ENGINE BLOCK |
| Description_ASM | Chevrolet:Big-Block Mark IV:396 (6.6L)/402 (6.6L)/427 (7.0L)/454 (7.4L)/502 (8.2L) |
| Description_DES | CRATE ENGINE |
| Description_EXT | Edelbrock part #450001 Big Block Chevy Siamese 4.50in. Bore with a 9.80 Deck height; Cast Iron block with a one piece rear main seal Big-Block Chevy Engine Block with 1-Piece Rear Main Seal |
| Description_FAB | Cam Bearing Bore ID 2.120 in. |
| Description_FAB | Cast Iron Cylinder Walls |
| Description_FAB | Designed/Cast/Manufactured In The USA |
| Description_FAB | Max Recommended Bore 4.600 in. |
| Description_FAB | Precision Machined To Our Very Own Specifications |
| Description_INV | Engine Block Bare BBC 4.50 bore 9.8 deck |
| Description_KEY | Engine Block; Big Block Chevy; Cast Iron; GEN V; VI; Edelbrock; 450001; Bare Block; BBC |
| Description_LAB | Big-Block Chevy Engine Block with 1-Piece Rear Main Seal |
| Description_MKT | Edelbrock part #450001 Big-Block Chevy Cast Iron Engine Block is cast and machined in the U.S.A. and made to last. Being that Edelbrock engine blocks are cast and machined in the U.S.A. allows us to precision machine them to our very own specifications. Engine block part #450001 is the perfect starting point for any Big-Block Chevy high performance engine build especially when used with an Edelbrock Total Power Package. When it comes to starting with the right base for your engine build.. make sure to choose the one made right here in the U.S.A.Edelbrock part #450001 Big-Block Chevy Cast Iron Engine Block is manufactured to the following specifications:- Block Type: Big-Block Chevy- Block Material: Cast Iron- Cylinder Wall: Siamese- Supplied Bore Size: 4.500"- Supplied Stroke Clearance: 4.500"- Max Recommended Bore: 4.600"- Max Recommended Stroke: 4.500"- Max Recommended C.I.: 598- Deck Height: 9.800"- Cam Bearing Bore ID: 2.120"- Camshaft Position: Standard BBC- Head Bolt Pattern: Standard BBC- Inside Head Stud Bosses: Yes- Lifter Bores: Standard BBC- Main Bearing Size: Standard BBC- Main Bearing Bore: 2.9375"- Main Caps: 4 Bolt Splayed Nodular Iron- Oil System: Main Priority- Oil Cooler Holes: Integral to Block- Rear Main Seal: 1-Piece- Hydraulic Roller Provisions: Accepts- Gen V, VI Link Bar- Stud and Bolt Holes: Blind Tapped- Tapped Holes: Standard Thread & Pitch- Timing Chain/Gears: Standard BBC Gen IV, V, VI- Timing Cover: Accepts- GEN V, VI 6 Bolt- Fuel Pump Boss: Yes- Starter: Standard Location- Clutch Linkage Boss: Yes |
| Description_SHO | { Sellable : Yes } |
| Description_SHP | { eo : 5in.} |
| height | 18.0 |
| length | 24.0 |
| weight | 240.0 |
| width | 21.5 |
